HOWO Vacuum Suction Truck Export Professional Introduction
Table of Contents
1. Product Overview
2. Working Principle
3. Daily Application Scenarios
4. Comparison with Traditional Sanitation Vehicles
5. Buying Guide
6. Operation and Maintenance Tips
7. Frequently Asked Questions
Conclusion
1. Product Overview
Core Product Keywords: HOWO Vacuum Suction Truck, Sanitation Truck, Wastewater Suction Truck, Sludge Suction Vehicle, Municipal Sanitation Equipment.
Sewage Suction Vehicle, also known as Vacuum Sewage Truck, is a professional sanitation vehicle fitted with a vacuum pump. It is specially developed for suction, transportation and discharge of sewage, sludge, mud and waste water.
Equipped with a high-efficiency vacuum system, this municipal sanitation vehicle generates negative pressure inside the airtight tank. It can suck up sewage, sludge, slurry and solid-liquid mixtures from sewers, septic tanks, drainpipes and sewage pits. All collected waste is kept in the tank and delivered to designated sites for unloading. It is widely used in urban sanitation, environmental protection projects, municipal works and rural sewage treatment.
Body Structure
The waste tank is made of thickened high-strength carbon steel via integral stamping and welding. Featuring excellent tightness and pressure resistance, it adapts to negative pressure suction and hydraulic discharge operations. The whole vehicle is refitted on authentic mature HOWO heavy-duty chassis, matched with fuel-saving high-torque diesel engine and stable transmission assembly. The supporting vacuum auxiliary components include vacuum pressure gauge, oil-water separator and anti-overflow protection device, which effectively prevent sewage backflow and vacuum pump damage. All welding parts and pressure-bearing pipelines pass strict air-tightness test before delivery to meet international export standards.
Core Advantages
1. High working efficiency: Adopts vacuum negative pressure suction mode, with fast suction and discharge speed, which can quickly clean wastewater, sludge and pipe blockages.
2. Wide application range: Suitable for sewer, septic tank, wastewater pit and other scenarios, capable of handling various liquid and solid mixed wastes.
3. Good sealing & environmental protection: The fully sealed tank avoids leakage and foul smell escape, reducing secondary pollution.
4. Flexible & labor-saving: Integrates suction, storage and transportation, reducing manual operation and cutting labor expenses.
2. Working Principle
The whole working system of HOWO Vacuum Suction Truck consists of three core modules: HOWO heavy-duty chassis power system, high-efficiency vacuum pumping assembly and pressure-resistant fully sealed sewage tank.
After engine ignition, the power take-off device transmits chassis power to drive the vacuum pump to operate continuously. The vacuum pump extracts internal air of the sealed tank to form stable negative pressure inside the tank body. Relying on atmospheric pressure difference, external sewage, sludge, mud and solid-liquid mixed waste are automatically sucked into the carbon steel storage tank through suction pipelines.
Built-in protective accessories can filter sundries and isolate oil and water, preventing waste liquid from flowing backward into the vacuum pump. After the tank is fully loaded, operators transport pollutants to designated disposal areas. By activating the hydraulic discharge system, the vehicle can finish rapid discharging, realizing one-stop mechanized operation of suction, storage and unloading.
3. Daily Application Scenarios
Urban Municipal Sanitation: Daily dredging of urban sewers, drainpipes and inspection wells, pipeline blockage cleaning and regular sewage disposal
Residential Community Operation: Septic tank cleaning, wastewater pit decontamination and domestic sewage disposal for residential districts and business parks
Rural Environmental Renovation: Rural domestic sewage treatment, village wastewater pit cleaning and decentralized sewage disposal
Municipal Environmental Projects: Urban black and odorous water treatment, river sludge suction and sediment cleaning
Emergency Sewage Treatment: Sudden pipeline sewage leakage disposal, rainwater stagnation cleaning after heavy rainfall
4. Comparison with Traditional Sanitation Vehicles
Vs Manual Sewage Cleaning Work: Traditional manual cleaning relies on manual digging and simple pumping tools, featuring low efficiency, massive labor cost and pervasive odor leakage, which easily causes urban secondary pollution. This HOWO vacuum suction truck realizes full-process mechanized operation, greatly saving manpower and optimizing on-site working environment.
Vs Ordinary Water Delivery Trucks: Common water trucks only support simple water transportation without negative pressure generating capacity, unable to suck viscous sludge and solid-liquid waste. The HOWO sewage suction truck is equipped with professional vacuum system, specially customized for sewage and sludge disposal with strong applicability.
Vs Non-standard Modified Sewage Trucks: Irregular refitted vehicles adopt thin ordinary steel tanks with poor pressure resistance, easy to deform and leak under long-term negative pressure. Our finished HOWO vehicle adopts thickened integrated stamping carbon steel tank, with stable sealing performance, standardized production and complete export qualifications.
HOWO Vacuum Suction Truck |
General | Chassis Brand | Sinotruk HOWO |
| Overall Dimension(L×W×H) | Approx 5900×2500×3800mm |
| GVW / Kerb Weight | 12000kg / approx 5000kg |
| Drive Orientation | Left-hand Drive (LHD) |
Cab | Cab Type | High-roof Sleeper Cab (Row-and-a-half) |
| Cab Capacity | 3 seats (1 driver + 2 passengers) with rear sleeper berth |
| Air Conditioner | Standard equipped |
| Power Windows | Standard equipped |
| Central Lock | Standard equipped |
Engine | Fuel Type | Diesel |
| Engine Brand | Sinotruk |
| Rated Power | 154HP/115kW |
| Displacement | 3760cc |
| Emission Standard | Euro 2 (National 2) |
Chassis Parameter | Drive Type | 4X2 |
| Transmission | 6 forward +1 reverse |
| Wheelbase/No.of axle | 3800mm / 2 axles |
| Tyre Specification | 8.25R16 |
| Tyre Number | 6pcs + 1 spare tyre |
| Max Speed | 90km/h |
| Paint | Standard: white cab + customized superstructure color |
Superstructure | Tank Body Capacity | 10000Liters (customizable) |
| Tank Body Material | 5-6mm thick Q235B high-strength carbon steel, fully welded construction; 304 stainless steel optional |
| Tank Body Structure | Horizontal cylindrical tank, with multi-group anti-wave baffles inside, reinforced dished tank head |
| Sewage Suction Pump | Chinese top brand |
| Pump Performance | Max vacuum degree ≥-0.09MPa, max suction flow 204m³/h, max suction depth ≥6m, stable large-flow suction, low noise |
| Hydraulic System | Domestic brand hydraulic pump & valves, working pressure 16-20MPa, for rear tank cover opening control |
| Control Mode | In-cab manual lever control with safety interlocks; optional wireless remote control |
| Discharge Function | Hydraulic opening rear tank cover with high-density silicone sealing ring, no tank body lifting function, adopts gravity flow + vacuum assisted discharge mode |
| Standard Accessories | Anti-overflow valve, sight glass window, 8m anti-wear suction hose, stainless steel filter screen, built-in flushing pipe, bottom drainage valve, safety railing & climbing ladder |
| Anti-corrosion | Epoxy primer + weather-resistant finish paint, anti-rust treatment for all metal parts |
5. Buying Guide
For overseas municipal sanitation departments, environmental engineering contractors and sanitation fleet purchasers, please confirm core configurations before procurement:
Genuine HOWO Original Chassis: Mass-produced verified heavy-duty chassis, stable power output, mature after-sales system and global spare parts supply channels to reduce overseas maintenance risks.
High-efficiency Complete Vacuum System: Matched professional vacuum pump and full-set safety accessories, stable negative pressure output, adapting to long-time continuous sanitation operation.
Integrated Pressure-resistant Carbon Steel Tank: Thickened high-strength carbon steel tank via integral stamping and welding, excellent pressure resistance and sealing performance to avoid sewage leakage.
Standard Export Configuration: Factory original refitting, supporting customized painting and basic function upgrading, providing full set of customs clearance and certification documents for overseas bidding and delivery.
6. Operation and Maintenance Tips
Standardized operation and regular maintenance can cut down failure rate and prolong vehicle service life:
6.1 Daily Operation Specifications
Check tank airtightness, vacuum pipeline connection status and vacuum pump oil level before vehicle startup
Do not suck ultra-large hard sundries to prevent pipeline blockage and vacuum pump abrasion
Strictly prohibit long-time overload suction operation to prevent tank body deformation caused by excessive negative pressure
Turn off the vacuum pump firstly before discharging sewage to effectively avoid liquid backflow damage
Clean residual sludge inside the tank after daily operation to prevent tank wall corrosion
6.2 Regular Maintenance Advice
Replace special vacuum pump lubricating oil every 12 months to guarantee stable suction performance
Clean vacuum pipelines and oil-water separator regularly to reduce dirt accumulation
Inspect tank welding seams and sealing strips quarterly, replace aging accessories timely to prevent leakage
Implement routine chassis maintenance according to official HOWO maintenance manual to keep driving stability
7. Frequently Asked Questions
Q1: Standard export name of this sanitation vehicle
A1: Official export names: HOWO Vacuum Suction Truck, HOWO Sewage Suction Vehicle, HOWO Municipal Sludge Suction Truck.
Q2: What working scenarios is this truck applicable to?
A2: It adapts to municipal sewer dredging, septic tank cleaning, rural sewage treatment, river remediation and environmental emergency disposal, covering urban and rural sanitation projects.
Q3: What is the core advantage of HOWO chassis?
A3: HOWO heavy-duty chassis features mature manufacturing technology, low failure rate, fuel-saving power performance and convenient global spare parts supply, which is highly suitable for overseas municipal sanitation work.
Q4: Can we customize vehicle configurations?
A4: Yes, we support customized outer painting color, upgraded anti-corrosion tank material and auxiliary functional parts to satisfy diverse national standards and client demands.
Q5: Can this vehicle meet international environmental protection requirements?
A5: The fully sealed tank structure realizes zero sewage leakage and odor isolation. All emission indexes comply with international environmental protection standards, and we can provide supporting certification documents.
Conclusion
HOWO Vacuum Suction Truck is a cost-effective and practical municipal sanitation equipment specially designed for global sewage disposal demands. Equipped with reliable original HOWO chassis and high-efficiency vacuum suction system, it integrates sewage suction, sealed transportation and hydraulic unloading functions.
With sturdy integral welding tank, excellent sealing performance, flexible operation and low maintenance cost, this vehicle solves the defects of low efficiency, easy leakage and high labor consumption of traditional sewage cleaning methods. Featuring stable quality and complete export qualifications, it has become preferable sanitation equipment for municipal environmental departments and engineering contractors worldwide.
